Studio 5000 Logix Designer software is a multi-disciplinary tool that allows you to manage every aspect of your control project smoothly, right from one interface. Versatile, scalable, and fully integrated, the Logix Designer application offers a seamless user experience across standard, safety, motion control, and more.
The new Version 36 release delivers on three major development areas: Expanded Hardware Support, Feature Enhancements, and Productivity.
New Hardware Support
- 5032 IO-Link
- 1756-L85ES
- iTRAK® 5750
New Capabilities
- Embedded OPC UA
- Granular Safety Signatures
- Additional Safety RLL Instructions
- Axis Test Mode for Safety
- Motion Indirect Referencing
Ease of Use
- Multi-device Interaction
- Workstation EDS Harmonization
Bringing OPC UA Communications to the Controller Level
Implement OPC UA communications at the controller level to enable seamless data integration between multiple platforms and simpler software architecture.
Key Features
- ControlLogix® 5580 (including safety and process versions)
- CompactLogix™ 5380 (including safety and process versions)
- Expose controller data via OPC UA
- As an OPC UA Server, or as an OPC UA Client
- Integrated OPC UA Security using FactoryTalk® Policy Manager v6.40 for certificate generation and management
Key Benefits
- Enables third-party connectivity at the controller
- Logix controllers can directly communicate with other automation devices with built-in OPC UA
- Enables seamless data integration between multiple platforms
- Allows for simpler software architecture
Limitless Potential of Logix Technology
The driving force behind this system, Logix technology, takes interoperability up a notch. It integrates batch, process, discrete, drives, safety, and motion control into one infrastructure, offering a unified solution for diverse applications and environments. With Logix 5000® controllers, you can design a system that fits your needs perfectly, from managing small machines to handling an entire plant.
Dive Into Enhanced Capabilities
Studio 5000 Logix Designer v36 is packed with new features to streamline your operations. Speed up project downloads on 5x80's, manage project documentation online, and leverage new safety ladder instructions for easier troubleshooting. The software also offers granular safety signatures at lower component levels for faster validation and testing time.
Automotive-Grade Hardware Support
ArmorBlock 5000® I/O has IP66/67/69K rated blocks that make it suitable for high-pressure washdown applications, including in the automotive industry.
Integrated Safety & High Performance
Studio 5000 Logix Designer v36 integrates with GuardLogix® 5580 to offer integrated safety on EtherNet/IP, I/O, and safety devices. It also boasts of high-performance CPUs to effectively power and manage your automation processes.
Intelligent Track System
Get your moving goods accurately with the flexible iTRAK® 5750 Intelligent Track System that uses a highly robust mechanical system to facilitate machine efficiency.
Mnemonic Updates & Additional Operators
Align your mnemonic functions with industry standards for better consistency and automatically convert the code over to multiple applications.
If Studio 5000 Logix Designer v36 sounds like the solution for your automation needs, then don’t hesitate to upgrade.
